| Type: | Amateur VHF transceiver |
| Frequency range: | 144-148 MHz (5 KHz steps) |
| Mode: | FM |
| RF Power output: | Hi: 10 W Lo: 1 W |
| Receiver system: | Dual conversion superheterodyne 1st IF: 10.7 MHz 2nd IF: 455 KHz |
| Sensitivity: | 0.3 uV (20 dB quieting) |
| Selectivity: | +/-6 KHz (-6 dB), +/-12 KHz (-60 dB) |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC +/-10% |
| Current drain: | RX: Max 0.5 A TX: 1-2.5 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 180*60*220 mm |
| Weight: | 2.7 Kg |
| Manufactured: | Japan, 19xx-19xx |
| Other: | +/- 600 KHz repeater split. |
 FT-227RA - user manual | 6827 kB |
| FT-227R - block | 383 kB |
 FT-227R - mod | 3 kB |
| FT-227R - PCB | 4594 kB |
| FT-227R - Schema | 5933 kB |
| FT-227R - user manual | 4952 kB |
