| Type: | Amateur VHF transceiver |
| Frequency range: | 144-146 MHz (Europe) 144-148 MHz (USA) |
| Mode: | FM |
| RF Power output: | Hi: 25 W Lo: 3 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max 300 mA TX: Max 5 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 150*50*174 mm |
| Weight: | 1.3 Kg |
| Manufactured: | 1983-19xx (Discontinued) |
| Other: | 10 memories |
 FT-230 - schema | 540 kB |
| FT-230 - user manual | 4338 kB |
