- Frequency range RX
- 144-146 MHz (DR-119E)
144-148 MHz (DR-119T) - TX
- 144-146 MHz (DR-119E)
144-148 MHz (DR-119T) - Modulations RX
- FM
- TX
- FM
- Frequency stability
- Tuning steps
- Sensitivity
- 0.16 µV (12 dB SINAD)
- Selectivity
- ±6 kHz (-6 dB)
±12 kHz (-60 dB) - Filters
- Receiver system
- Double conversion
- IF-frequencies
- 1st: 10.7 MHz
2nd: 455 kHz - Image rejection
- Aerial
- 50Ω
- RF-output
- 5 / 50 W
- Audio output
- 2 W into 8 ohm @ 10% THD
- Memories
- Power requirements
- 13.8V DC
- Current drain RX
- 0.5 A
- TX
- 10 A max
- Manufactured
- Between 200x and 200x in Japan
- Dimensions (w×h×d)
- 140 × 40 × 170 mm (5.51 × 1.57 × 6.69 in)
- Weight
- 1.1 kg (2.4 lbs)
- Features
- DTMF encoder (US version
 Alinco_DR-119T_DR-119E_user-manual.pdf | 386 kB |
