| Type: | HF receiver |
| Frequency range: | 0.1-30 MHz (108-174 MHz option: VC-20) |
| Mode: | AM/FM/SSB/CW |
| Receiver system: | Dual conversion superheterodyne (AM/SSB/CW/FSK) Triple conversion superheterodyne (FM) 1st IF: 58.1125 MHz 2nd IF: 8.83 MHz 3rd IF: 455 KHz |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC or mains |
| Current drain: | Max 2 A |
| Impedance: | 50/500 ohms |
| Dimensions (W*H*D): | 270*96*270 mm |
| Weight: | 5.6 Kg |
| Manufactured: | Japan, 1986-1996 (Discontinued) |
| Other: | 100 memories. |
 R-5000_manuale_utente_italiano.pdf | 3079 kB |
 R-5000_modifications.zip | 3335 kB |
| R-5000_schematic_diagram.pdf | 1605 kB |
| R-5000_service_manual.pdf | 10343 kB |
| R-5000_user_manual.pdf | 3241 kB |
