| Type: | Amateur HF transceiver |
| Frequency range: | TX: 10-160 m + WARC / 6 m RX: 0.5-30 / 50-54 MHz |
| Mode: | AM/FM/SSB/CW |
| RF Power output: | HF: 100 W (AM: 40 W) 6 m: 50 W (AM: 20 W) |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max 2.5 A TX: Max 20.5 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 270*96*328 mm |
| Weight: | 6.9 Kg |
| Manufactured: | 19xx-19xx (Discontinued) |
 TS-690S - service manual | 34699 kB |
| TS-690S - manuale utente in italiano | 19128 kB |
