Veicolare Bibanda Wouxun KG-UV950P 50W Qual Cross Band Car Mobile Radio Repeater
Veicolare Bibanda 50W
SPECIFICATIONS
| GENERAL | |
| Type: | Amateur HF/VHF/UHF transceiver |
| Frequency range: | TX: 26-30 / 50-54 / 136-174 / 400-481 MHz RX: 26-30 / 50-54 / 65-181 / 320-350 / 400-481 / 700-988 MHz |
| Tuning steps: | 5 / 6.25 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 KHz |
| Mode: | TX: FM/NFM RX: AM/FM/NFM/WFM |
| Channels/memory management: | 999 regular with alpha tags |
| Repeater shift/offset: | ±? |
| Power supply: | 13.8 VDC ±15% |
| Current drain/power consumption: | RX: ? mA TX: ? A |
| Antenna impedance/connector: | 50 ohms / SO-239 |
| Dimensions (W*H*D): | 140*44*207 mm (5.5*1.73*8.15") |
| Weight: | 1.44 Kg (3.17 lbs) |
| Other features: | CTCSS/DCS, DTMF, Caller ID, Detachable head, cross-band repeat, Scrambler, Voice guide, Selectable three color backlight, Twin RX |
| RECEIVER SECTION | |
| Receiver system: | ? conversion superheterodyne 1st IF: ? MHz 2nd IF: ? KHz |
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power/speaker: | ? W at ?% distortion / ? ohms |
| External speaker connector: | 3.5 mm |
| TRANSMITTER SECTION | |
| RF output power (HF / 6 m / 2 m / 70 cm): |
Hi: ? / ? / 50 / 40 W Mid1: ? / ? / 20 / 20 W Mid2: ? / ? / 10 / 10 W Lo: 5 / 5 / 5 / 5 W |
| Modulation system: | |
| Max FM deviation: | FM: ±5 KHz NFM: ±2.5 KHz |
| Spurious emissions: | Less than -? dB |
| Microphone connector/impedance: | ?-pin modular / ? ohms |
