BIBANDA VHF/UHF PORTATILE
| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | TX: 144-146 / 430-440 MHz (Europe) RX: 138-200 / 300-500 / 800-1000 MHz |
| Mode: | FM (15 KHz) |
| RF Power output: | Hi: 5/5 W Mid: 2/2 W Lo: 350/350 mW |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 6-16 VDC (7.2 VDC nominal) |
| Current drain: | RX: 17-100 mA TX: Max 1.3 A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 55*157*31 mm |
| Weight: | 450 gr (Batteries & antenna included) |
| Manufactured: | Japan, 1989-19xx |
| Other: | DTMF. CTCSS/PL. Twin RX |
 Standard_C528_service_manual.pdf | 5744 kB |
| Standard_C528_user_manual.pdf | 3810 kB |
