UHF Veicolare
| Type: | Amateur UHF transceiver |
| Frequency range: | 430-440 MHz (12.5/25 KHz steps) |
| Mode: | FM |
| RF Power output: | Hi: 35 W Lo: 4 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: 500-700 mA TX: Max 8.5 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 160*50*175 mm |
| Weight: | 1.5 Kg |
| Manufactured: | Japan, 1987-19xx |
| Other: | New price 1989 in Sweden: 4275:- SEK |
 FT-711 - schema | 223 kB |
