Type: Amateur VHF transceiver
Frequency range: TX: 144-146 MHz (Europe)
TX: 144-148 MHz (USA)
RX: 140-174 MHz
Mode: FM
RF Power output: Hi: 5 W
Lo3: 3 W
Lo2: 1.5
Lo1: 0.5 W
Receiver system: N/A
Sensitivity: N/A
Selectivity: N/A
Image rejection: N/A
Voltage: 5.5-16 VDC
Current drain: RX: 8-190 mA
TX: Max 1.6 A
Impedance: 50 ohms
Dimensions (W*H*D): 55*146*33 mm
Weight: 430 g (with FNB-27)
Manufactured: 1993-199x (Discontinued)
Other: 41 memories
