Frequency range:10-160 m + WARC
Mode:AM/SSB/CW (AM TX and FM RX/TX option)
RF Power output:100 W
Receiver system:Dual conversion superheterodyne
1st IF: 8.2 MHz
2nd IF: 455 KHz
Sensitivity:AM: 1 uV (10 dB (S+N)/N)
FM: 0.4 uV (20 dB quieting)
SSB: 0.25 uV (10 dB (S+N)/N)
CW: 0.18 uV (10 dB (S+N)/N)
Selectivity:AM/SSB/CW: 2.7 KHz (-6 dB), 4.8 KHz (-60 dB)
Image rejection:>70 dB
Voltage:Mains
Current drain:RX: ? A
TX: Max ? A
Impedance:50 ohms, SO-239
Dimensions (W*H*D):368*129*310 mm
Weight:15 Kg
Manufactured:Japan, 1982-1984 (Discontinued)
Other:Tube hybrid





Allegati:
Scarica questo file (FT102_mod.zip)FT-102 - Modifiche2055 kB
Scarica questo file (FT102_sch_VA3VFO.pdf)schema965 kB
Scarica questo file (FT102_serv.pdf)manuale di servizio6433 kB
Scarica questo file (FT102_user_VA3VFO.pdf)manuale d'uso10183 kB
