| Type: | Amateur UHF transceiver |
| Frequency range: | TX: 430-440 MHz RX: 400-470 MHz (5 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 KHz steps) |
| Mode: | FM (15 KHz BW) |
| RF Power output: | Hi: 5 W Lo: 0.5 W |
| Receiver system: | Dual conversion superheterodyne 1st IF: 30.85 MHz 2nd IF: 450 KHz |
| Sensitivity: | 0.16 uV (12 dB SINAD) |
| Selectivity: | 15 KHz (-6 dB), 30 KHz (-60 dB) |
| Image rejection: | 50 dB |
| Voltage: | 4.5-16 VDC |
| Current drain: | RX: 15-150 mA TX: 0.5-1.4 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 57*110*27 mm |
| Weight: | 300 gr |
| Manufactured: | Japan, 1998-199x (Discontinued) |
| Other: | 40 memories. CTCSS/PL, DTMF |
 IC-T22-T42_user_manual.pdf | 9699 kB |
