| Type: | Amateur UHF transceiver |
| Frequency range: | 430-436 MHz |
| Mode: | SSB/CW |
| RF Power output: | 3 W (PEP) |
| Receiver system: | Dual conversion superheterodyne 1st IF: 57.6 MHz 2nd IF: 10.74 MHz |
| Sensitivity: | 0.4 uV (10 dB S+N/N) |
| Selectivity: | 2.4 KHz (-6 dB), 4.8 KHz (-60 dB) |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: 40 mA TX: Max 1 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 61*183*162 mm |
| Weight: | 2 Kg (With batteries) |
| Manufactured: | Japan, 1978-19xx (Discontinued) |
| Other: | VXO New price 1978 in Sweden: 2750:- SEK |
 IC-402_block_diagram.pdf | 85 kB |
 IC-402_modifications.zip | 335 kB |
| IC-402_pcb.pdf | 466 kB |
| IC-402_schematic_diagram.pdf | 380 kB |
