| Type: | Professional land mobile transceiver |
| Frequency range: | TX: 0.5-30 MHz RX: 0.03-30 MHz |
| Mode: | AM/SSB/CW/RTTY |
| RF Power output: | SSB/CW/RTTY: 2-100 W AM: 2-40 W |
| Sensitivity: | AM (10 dB S/N): 13 uV (0.5-1.6 MHz), 2 uV (1.6-30 MHz) SSB/CW/RTTY (10 dB S/N): 0.16 uV (1.6-30 MHz) |
| Selectivity: | AM: 6 KHz (-6 dB), 20 KHz (-40 dB) SSB/CW/RTTY: 2.1 KHz (-6 dB), 4.5 KHz (-60 dB) |
| Image rejection: | Better than 70 dB (1.6-30 MHz) |
| Voltage: | 13.8 VDC +/- 15% |
| Current drain: | RX: 1.3-2 A TX: Max 20 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 240*95*239 mm |
| Weight: | 3.8 Kg |
| Manufactured: | 200x-200x |
| Other: | 99 memories |
 IC-78_service_manual.pdf | 11889 kB |
| IC-78_user_manual.pdf | 2137 kB |
