| Type: | Amateur HF/VHF transceiver |
| Frequency range: | TX: 10-160 m + WARC/50-54 MHz RX: 0.03-33 / 46.2-61.1 MHz |
| Mode: | AM/FM/SSB/CW |
| RF Power output: | HF: 10-100 W (AM 10-40 W) 6 m: 1-10 W (AM 1-4 W) |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: ? A TX: Max 20 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | ? mm |
| Weight: | ? Kg |
| Manufactured: | Japan, 1989-199x (Discontinued) |
| Other: | New price 1990 in Sweden: 10990:- SEK |
 IC-726_user_manual.pdf | 3111 kB |
