| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: | 25-520 / 760-1300 MHz 5 / 12.5 / 30 / 50 KHz steps |
| Mode: | AM/FM/WFM |
| Receiver system: | N/A |
| Sensitivity: | AM (20 dB S/N): 25-1000 MHz 2 uV, 1000-1300 MHz 5 uV FM (20 dB S/N): 25-1000 0.5 uV, 1000-1300 MHz 3 uV WFM (30 dB S/N): 25-1000 MHz 3 uV, 1000-1300 MHz 10 uV |
| Selectivity: | AM/FM: 18 KHz (-6 dB), 30 KHz (-50 dB) WFM: 300 KHz (-6 dB), 600 KHz (-60 dB) |
| Image rejection: | N/A |
| Voltage: | 12 VDC or mains |
| Current drain: | Max ? mA |
| Impedance: | 50-75 ohms, BNC |
| Dimensions (W*H*D): | 220*76*205 mm |
| Weight: | 2.2 Kg |
| Manufactured: | Japan, 199x-199x (By GRE) |
| Other: | 400 channels @ 26 ch/sec. Sound squelch. |
 Realistic_PRO-2006_service_manual_4.0.pdf | 5092 kB |
| Realistic_PRO-2006_user_manual.pdf | 1003 kB |
