| Type: | Amateur HF/CB transceiver |
| Frequency range: | 26-30 MHz (100/10/1 KHz/100 Hz steps) |
| Mode: | AM/FM/SSB/CW |
| RF Power output: | Hi: 100 W (25 W AM) Lo: 20 W (5 W AM) |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | >50 dB |
| Voltage: | 11-16 VDC |
| Current drain: | RX: Max ? A TX: Max 20 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 156*61*290 mm |
| Weight: | ? Kg |
| Manufactured: | Japan, 197x-197x (Discontinued) |
| Other: | Also known as "The coffeewarmer" Microphone is switchable for use as a speaker-mike. This is an interesting feature I've never seen before in a mobile radio. Very useful in a noisy vehicle. |
 Sommerkamp_TS788DX_modifiche.zip | 0.9 kB |
 Sommerkamp_TS788DX_user_manual.pdf | 68528 kB |
