UHF Veicolare
| Type: | Amateur UHF transceiver |
| Frequency range: | 430-440 MHz |
| Mode: | FM/SSB/CW |
| RF Power output: | 1 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max 100 mA TX: Max 750 mA |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | ? mm |
| Weight: | ? Kg |
| Manufactured: | 198x-19xx (Discontinued) |
| Other: | 10 memories |
 FT-790R - manuale utente italiano | 2235 kB |
| FT-790R - user manual | 5874 kB |
| FT-790R - block diagram | 107 kB |
| FT-790R - layout pcb | 851 kB |
 FT-790 - mod | 1 kB |
| FT-790R - schematic diagram | 405 kB |
