| Type: | Amateur HF/VHF/UHF transceiver |
| Frequency range: | TX: 10-160 m + WARC / 6 m / 2 m / 70 cm RX: 0.1-76 / 108-174 / 420-512 MHz |
| Mode: | AM/FM/SSB/CW and WFM (RX only) |
| RF Power output: | 6-160 m: 100 W 2 m: 50 W 70 cm: 20 W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: 0.6-1 A TX: Max 22 A |
| Impedance: | 50 ohms, 2*SO-239 (USA), 1*SO-239 + 1*N-type (Europe) |
| Dimensions (W*H*D): | 155*52*233 mm |
| Weight: | 2.1 Kg |
| Manufactured: | 2003-2004 (Discontinued) |
| Other: | Built-in keyer. Beacon mode. 32 color display. CTCSS. 200 memories. Detachable front panel. DSP option |
SOftware di controllo via CAR
- Ham Radio Deluxe (Gratuito) http://www.ham-radio-deluxe.com/
- SuperCOntroll (Commerciale) http://www.supercontrol.de/
 FT-857 - Interfaccia CAT e DATI OPTOISOLATA | 696 kB |
| FT-857 - ESSB | 274 kB |
| FT-857D - manuale Italiano | 3810 kB |
| FT-857 - Sottomenù | 81 kB |
| Ft-857 - Mod Collection | 1229 kB |
| FT-857 e FT-897 - Mod Squelch | 193 kB |
| FT-857 - Manual english | 3315 kB |
| FT-857 - Service Manual | 12831 kB |
| FT-857 - modificare il transceiver della Yaesu | 344 kB |
