| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | 144-146 / 430-440 MHz (Europe) 144-148 / 430-450 MHz (USA) RX: 108-520 / 700-999 MHz (cellular blocked in the US) |
| Mode: | TX: FM RX: AM/FM |
| RF Power output: | Hi: 5/5 W Mid: 2/2 W Lo: 0.5/0.5 W |
| Sensitivity: | 0.16 uV (12 dB SINAD - 140-150 MHz) 0.2 uV (12 dB SINAD - 420-470 MHz) |
| Selectivity: | 12 KHz (-6 dB), 35 KHz (-60 dB) |
| Image rejection: | N/A |
| Voltage: | Nominal: 7.2 VDC (battery pack), 6-16 VDC (external) |
| Current drain: | RX: 45-125 mA TX: Max 1.5 A |
| Impedance: | 50 ohms, SMA |
| Dimensions (W*H*D): | 58*109*30 mm |
| Weight: | 370 gr |
| Manufactured: | 2004-200x |
| Other: | 1000 memories with alpha-tags. CTCSS & DCS. WIRES II. ARTS. Emergency Automatic ID (EAI). |
| Related documents: |
FT-60 Commander
Programming software for the Yaesu FT-60(R).
Programming software for the Yaesu FT-60(R).
Features:
- Read and Write to the FT-60
- Edit/Move/Cut/Copy/Paste main memory channels and scan edge memories
- Edit Home Memories
- Edit Set Mode Settings
- Edit VFO data
- Import/Export CSVs
- Sort memories by tag or freq
- Check for duplicates
- Print memories
- Import ARRL TravelPlus Files
- Import from VX-2, VX-5, VX-7, VR-120, IC-R2, IC-Q7 files
- Open ADMS FT-60 .rdf files (must save to .60r file)
 FT-60E - manuale utente in italiano | 2197 kB |
 Programming software for the Yaesu FT-60R | 2487 kB |
| FT-60 - modifiche | 2169 kB |
| FT-60 - service manual | 6296 kB |
| FT-60R - user manual english | 2242 kB |
