| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | TX: 144-146 / 430-440 MHz (Europe) RX: 100-230 / 300-530 / 810-1000 MHz |
| Mode: | FM |
| RF Power output: | Hi: 50/35 W Lo: ?/? W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: 350-? mA TX: Max 9.5 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 100*30*138 mm |
| Weight: | 640 gr |
| Manufactured: | 19xx-19xx |
 FT-90R user manual english | 631 kB |
| FT-90R - manuale utente italiano | 1213 kB |
| FT-90R manuale utente in italiano | 1482 kB |
| FT-90R schematic diagram | 1049 kB |
