| Frequency range: | TX: 10-160 m RX: 10-160 m + CB and WWV |
| Mode: | AM/SSB/CW/FSK |
| RF Power output: | SSB: 200 W (PEP input) CW: 200 W (input) AM/FSK: 50 W (input) |
| Sensitivity: | 0.25 uV (10 dB S/N) |
| Selectivity: | SSB: 2.4 KHz (-6 dB), 4 KHz (-60 dB) CW/FSK: 0.6 KHz (-6 dB), 4 KHz (-60 dB) AM: 6 KHz (-6 dB), 12 KHz (-60 dB) |
| Image rejection: | Better than 60 dB (15-160 m) Better than 50 dB (10 m) |
| Voltage: | 13.5 VDC |
| Current drain: | RX: Max 1.1 A TX: Max 21 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 280*125*370 mm |
| Weight: | 9 Kg |
| Manufactured: | 197x-19xx |
| Other: | Analog readout |
 FT-301 - user manual | 3980 kB |
