| Frequency range: | 10-160 m + WARC (Early versions did NOT feature the WARC bands) |
| Mode: | AM/SSB/CW |
| RF Power output: | AM: 30 W (DC) SSB/CW: 100 W |
| Sensitivity: | AM: 0.5 uV (10 dB S/N) SSB/CW: 0.25 uV (10 dB S/N) |
| Selectivity: | 2.4 KHz (-6 dB), 4 KHz (-60 dB) |
| Image rejection: | >60 dB (15-160 m) >50 dB (10 m) |
| Voltage: | Mains (13.8 VDC option) |
| Current drain: | RX: 5.5 A (1.1 A heater off) TX: Max 21 A |
| Impedance: | 50-75 ohms, SO-239 |
| Dimensions (W*H*D): | 345*157*326 mm |
| Weight: | 15 Kg |
| Manufactured: | 1979-19xx |
 manuale di servizio | 20133 kB |
| manuale d'uso - english | 2985 kB |
| FT-101ZD - Manuale utente in italiano | 2855 kB |
