R-599d

Type: HF receiver
Frequency range: 10-160 m (2m & 6m options)
Mode: AM/FM/SSB/CW
Receiver system: N/A
Sensitivity: AM (10 dB S+N/N):
1.8-28 MHz: 1.5 uV
50 MHz: 3 uV
144 MHz: 3 uV
SSB (10 dB S+N/N):
1.8-28 MHz: 0.25 uV
50 MHz: 0.5 uV
144 MHz: 0.5 uV
Selectivity: AM: 5 KHz (-6 dB), 12 KHz (60 dB)
FM: 20 KHz (-6 dB), 120 KHz (-60 dB)
SSB: 2.4 KHz (-6 dB), 4.4 KHz (-60 dB)
CW: 500 Hz (-6 dB), 1.5 KHz (-60 dB)
Image rejection: >50 dB
Voltage: 12-15 VDC or mains
Current drain: Max 1 A
Impedance: 50-75 ohms, SO-239
Dimensions (W*H*D): 270*140*310 mm
Weight: 5.7 Kg
Manufactured: Japan, 1976-1979 (Discontinued)
